User Guide for Delixi Inverter CDI-EM60/CDI-EM61 Series Manual

I. Introduction to Operation Panel Functions

The Delixi Inverter CDI-EM60/CDI-EM61 series is equipped with an intuitive and user-friendly operation panel, enabling users to easily set and adjust parameters.

CDI-EM60 and EM61 series frequency converter operation panel function diagram

Key Components of the Operation Panel

  1. Display Screen: Displays various operation parameters, status indicators, and error messages.
  2. Function Keys:
    • RUN: Starts the inverter.
    • STOP: Stops the inverter.
    • JOG: Enables jogging (inching) operation.
    • PROG: Enters programming mode for parameter adjustment.
    • ESC/RESET: Exits programming mode or resets errors.
    • ▲/▼: Adjusts parameter values.
    • ▶/◀: Navigates through menus.

Basic Operations

  1. Power On: Ensure the inverter is properly powered on.
  2. Navigation: Use the ▶/◀ keys to navigate through different menus and parameters.
  3. Value Adjustment: Use the ▲/▼ keys to adjust parameter values.
  4. Save & Exit: Press the ESC key to save changes and exit programming mode.

II. Using Simplified Internal Relay Programming Function

The Simplified Internal Relay Programming function allows users to perform basic logical operations using the inverter’s internal relays.

Steps to Configure

  1. Enter Programming Mode: Press the PROG key to enter programming mode.
  2. Navigate to Relay Control Parameters: Use the ▶/◀ keys to navigate to the relay control parameters (P3.2 group).
  3. Set Relay Logic:
    • P3.2.00: Set the control logic for each relay (M1-M5).
    • P3.2.01-P3.2.06: Configure the input conditions for each relay.
    • P3.2.07-P3.2.11: Define the output actions for each relay.
  4. Set Delay Times:
    • P3.2.12-P3.2.16: Set the on-delay times for each relay.
    • P3.2.17-P3.2.21: Set the off-delay times for each relay.
  5. Save Settings: Press the ESC key to save changes and exit programming mode.
CDI-EM60 and EM61 series VFD standard wiring diagram

III. Using Internal Timer Function

The Internal Timer function provides users with timing control capabilities.

Steps to Configure

  1. Enter Programming Mode: Press the PROG key to enter programming mode.
  2. Navigate to Timer Control Parameters: Use the ▶/◀ keys to navigate to the timer control parameters (P3.2.22-P3.2.25).
  3. Set Timer Control:
    • P3.2.23: Configure timer start/stop conditions.
    • P3.2.24/P3.2.25: Set the timer duration for Timer 1 and Timer 2.
  4. Set Timer Units:
    • P3.2.23: Select the time units (seconds, minutes, or hours).
  5. Save Settings: Press the ESC key to save changes and exit programming mode.

IV. Using Internal Calculation Module Function

The Internal Calculation Module function enables users to perform simple arithmetic operations and logical judgments.

Steps to Configure

  1. Enter Programming Mode: Press the PROG key to enter programming mode.
  2. Navigate to Calculation Module Parameters: Use the ▶/◀ keys to navigate to the calculation module parameters (P3.2.26-P3.2.39).
  3. Select Operation Type:
    • P3.2.26: Choose the type of operation (addition, subtraction, multiplication, division, comparison, etc.).
  4. Set Input Addresses:
    • P3.2.28/P3.2.29: Specify the input addresses (A and B) for the operation.
  5. Set Scaling Factors:
    • P3.2.30/P3.2.33: Define the scaling factors for the operation results.
  6. Configure Output:
    • Set the output address or action for the calculation result.
  7. Save Settings: Press the ESC key to save changes and exit programming mode.

V. Restoring Parameters to Factory Defaults

To restore the inverter parameters to their factory defaults, follow these steps:

  1. Enter Programming Mode: Press the PROG key to enter programming mode.
  2. Navigate to Parameter Initialization: Use the ▶/◀ keys to navigate to the parameter initialization parameter (P5.0.19).
  3. Select Initialization Option:
    • Set P5.0.19 to “09” to restore factory parameters, excluding motor parameters, calibration parameters, and password parameters.
    • Set P5.0.19 to “19” to restore factory parameters, excluding motor parameters and password parameters.
  4. Confirm Initialization: Press the RUN key to confirm the initialization process. The inverter will restart automatically.
  5. Exit Programming Mode: Press the ESC key to exit programming mode.

By following these guidelines, users can efficiently utilize the advanced features of the Delixi Inverter CDI-EM60/CDI-EM61 series, ensuring optimal performance and reliable operation.

Posted on Leave a comment

SEW Servo MDX60B/MDX61B Series User Guide and Fault F196.4 Meaning and Solutions

The SEW Servo Drives MDX60B/MDX61B series are widely used in automation control systems, known for their high performance and reliability, meeting the needs of various industrial applications. This guide will provide a detailed introduction to the usage, parameter settings, common faults, and troubleshooting methods of this series, with a focus on explaining the meaning of fault code F196.4 and its resolution.

On site maintenance of SEW servo

1. SEW Servo Operation Panel DBG60B Features

The SEW Servo Drives MDX60B/MDX61B series are equipped with the DBG60B operation panel, which provides an easy-to-use interface for monitoring and configuring the drive parameters.

Main Features:

  • Operating Status Display: The operation panel can display the current status of the servo drive, including alarms, operating parameters, and other critical information.
  • Parameter Settings: Users can set and adjust various parameters to customize the operation of the drive for specific applications.
Setting “Heat Sink Temperature” and “Operating Time”:
  1. On the DBG60B panel, press the “MENU” button to enter the parameter setting mode.
  2. Navigate to the “Parameters” menu and find the monitoring options for “Heat Sink Temperature” and “Operating Time.”
  3. Enable these parameters for display.
  4. After setting, press the “Confirm” button to save the settings. From then on, the operation panel will show the heat sink temperature and operating time, allowing users to monitor the drive’s operating conditions.
Restoring Factory Default Parameters:
  1. On the DBG60B panel, press the “MENU” button to enter the parameter setting mode.
  2. Select “Restore Factory Settings” from the menu.
  3. Confirm the restoration of factory settings, and the system will reset all parameters to their default values. This is useful for initializing the device or correcting configuration errors.
Setting Password and Locking Parameters:
  1. In the “Menu” options, select “Password Settings.”
  2. Enter the default password (usually “0000”), then set a new password.
  3. Enable “Lock Parameters” to prevent unauthorized modification of critical settings. This step is crucial for preventing accidental changes and ensuring the safety of the equipment.
SEW-MDX6061 Standard Wiring Diagram

2. Setting External Terminal Forward/Reverse and External Potentiometer (Analog) for Frequency Control

The SEW Servo MDX60B/MDX61B series supports controlling forward/reverse rotation and adjusting the speed via an external potentiometer or other analog input signals. This is useful for manual speed and direction control in various applications.

Wiring Requirements:
  • Forward/Reverse Control: Use digital input terminals (e.g., X10-X12) to connect external pushbuttons or switches for forward and reverse control.
    • For example, connect a switch between terminals X10 and X11 to implement forward/reverse control.
  • Analog Speed Control via Potentiometer: Use the analog input terminal (e.g., X13) to connect an external potentiometer (10kΩ) or other analog devices that provide a 0-10V or 4-20mA signal to control the speed.
    • Terminal X13 is used for the analog input to set the motor speed.
Parameter Settings:
  1. Setting External Forward/Reverse:
    • In the parameter menu, set the “Control Mode” to “External Control.” Map the input terminals X10-X12 to forward/reverse control functions.
    • Set the input signal correctly (e.g., X10 for forward, X11 for reverse).
  2. Setting Analog Potentiometer for Speed Control:
    • In the parameters, set the “Speed Control Mode” to “Analog Input Speed Control” and select the appropriate input terminal (e.g., X13).
    • Ensure the correct analog signal range (e.g., 0-10V or 4-20mA) is selected to ensure accurate speed control.
SEW MDX61B physical picture

3. Common Fault Codes in SEW Servo Drives and Solutions

The SEW Servo MDX60B/MDX61B series may show several common fault codes, including but not limited to:

  • F0001 – Overload Protection: This error indicates that the load on the servo motor exceeds its rated capacity, triggering the protection mechanism.
    • Solution: Check if the load is too heavy. Adjust the load or reduce the drive output power accordingly.
  • F0102 – Motor Overheating: If the motor temperature exceeds the set threshold, this fault is triggered.
    • Solution: Check the cooling system, ensure proper airflow, and remove any obstructions that may affect cooling.
  • F0203 – Encoder Signal Loss: When the encoder signal is lost or unstable, the drive cannot get accurate position feedback.
    • Solution: Inspect the encoder connection, ensuring that the signal wires are intact and not damaged.
F196.4 FAULT

4. Fault F196.4 Meaning and How to Repair It

F196.4 is a fault indicating an issue with the “Inverter Coupling Reference Voltage”, specifically a defective inverter coupling. This fault typically occurs when the reference voltage in the inverter’s coupling circuit is unstable or fails.

F196.4 Fault Analysis:
  • Fault Description: The F196.4 fault code generally indicates that the coupling module within the inverter cannot function properly, failing to generate or maintain the required reference voltage. This leads to abnormal signal transmission, affecting the inverter’s operation.
  • Possible Causes:
    1. Failure of the coupling module’s internal power supply, preventing the generation of reference voltage.
    2. Faulty circuit components (e.g., capacitors, resistors) within the coupling module.
    3. External power supply issues or unstable voltage leading to abnormal reference voltage.
Solution:
  1. Check the Coupling Module: Inspect the coupling module for any visible damage or loose connections.
  2. Measure the Voltage: Use a multimeter or oscilloscope to check the output voltage of the coupling module and ensure it is stable and within the specified range.
  3. Replace Defective Components: If the coupling module or related components are found to be defective, replace them with the correct parts.
  4. Verify Power Supply Stability: Ensure the power supply system is stable and the wiring connections are correct.

If the issue persists after these checks, it is recommended to contact SEW-EURODRIVE technical support for further diagnosis and assistance.


Conclusion

The SEW Servo MDX60B/MDX61B series drives, with their high efficiency and versatile functions, are widely used in industrial automation. The DBG60B operation panel provides an intuitive interface for setting parameters, monitoring status, and making adjustments as needed. Understanding common fault codes and their solutions is essential for maintaining system reliability. In particular, F196.4 indicates a serious issue with the inverter’s coupling reference voltage, which requires immediate attention and repair. By following the troubleshooting steps outlined in this guide, users can ensure the smooth operation and longevity of their servo drive systems.

Posted on Leave a comment

User Manual Guide for SUNYE CM530 Series Frequency Converter

The SUNYE CM530 series frequency converter is a high-performance flux vector control frequency converter widely used in various industrial control applications. This article aims to provide users with a detailed guide covering operation panel functions, terminal wiring and parameter settings, fault code analysis and troubleshooting methods, helping users better use and maintain the frequency converter.

CM530 Operation Panel Function Diagram
I. Introduction to Operation Panel Functions

The operation panel of the CM530 frequency converter integrates multiple functions, including parameter setting, status monitoring, and operation control. Here are the introductions to the main functions:

  1. Restoring Factory Settings:
    • In the stopped state of the frequency converter, enter the parameter setting interface through the operation panel.
    • Select function code F0-28 and set its value to “1”. Then press the confirmation key, and the frequency converter will restore factory settings.
  2. Setting and Resetting Passwords:
    • Setting Password: Select function code F7-49 and set its value to a non-zero value to enable parameter protection. After setting, entering the parameter setting menu again requires a password.
    • Resetting Password: Under password protection, set F7-49 to “0” to disable password protection.
  3. Setting Parameter Protection:
    • Parameter protection is realized through passwords. After setting the password, unauthorized users cannot modify the frequency converter parameters, ensuring the stability and security of device operation.
II. Terminal Forward/Reverse Control and External Potentiometer Speed Regulation

The CM530 frequency converter supports forward/reverse control via terminals and speed regulation using an external potentiometer. The specific wiring and parameter settings are as follows:

  1. Forward/Reverse Control Wiring:
    • Connect the forward control line to the DI1 terminal and the reverse control line to the DI2 terminal.
    • In the parameter setting interface, set F5-00 to “1” (forward operation) and F5-01 to “2” (reverse operation).
  2. External Potentiometer Speed Regulation Wiring:
    • Connect the center tap of the external potentiometer to the GND of the AI1 terminal, and the other ends to AI1 and +10V, respectively.
    • In the parameter setting interface, set F0-06 to “2” (AI1), selecting AI1 as the main frequency source.
  3. Parameter Settings:
    • Adjust parameters such as F0-14 (maximum operating frequency) according to actual needs to meet the speed regulation range requirements.
III. Fault Code Analysis and Troubleshooting Methods

The CM530 frequency converter features comprehensive fault protection functions. When a fault occurs, the corresponding fault code will be displayed on the operation panel. Here are some common fault codes, their meanings, and troubleshooting methods:

  1. Err01: Inverter Unit Protection
    • Meaning: The inverter has encountered a severe fault, such as overcurrent or overvoltage.
    • Solution: Check the motor and load for abnormalities, and inspect the input and output lines of the frequency converter for short circuits or grounding. If the issue cannot be resolved, contact after-sales service.
  2. Err02: Hardware Overcurrent Protection
    • Meaning: The output current of the frequency converter exceeds the rated value.
    • Solution: Check the motor and load for overload, inspect the motor cable for excessive length or poor insulation, and appropriately adjust the frequency converter parameters.
  3. Err03: Hardware Overvoltage Protection
    • Meaning: The DC bus voltage of the frequency converter is too high.
    • Solution: Check the input power supply voltage for being too high and inspect the braking resistor and braking unit for normal operation.
  4. Err13/Err14: Frequency Converter/Motor Overload
    • Meaning: The frequency converter or motor has been overloaded for an extended period.
    • Solution: Check the load for being too large, appropriately adjust the load or increase the motor capacity, and inspect the motor for being blocked or jammed.
IV. Conclusion
CM530 standard wiring diagram

The SUNYE CM530 series frequency converter user manual provides users with comprehensive operation guidance and troubleshooting methods. By proficiently mastering the functions of the operation panel, reasonably setting terminal wiring and parameters, and promptly analyzing and resolving fault codes, users can ensure the stable operation and efficient work of the frequency converter. Additionally, users should regularly perform maintenance and servicing of the frequency converter to extend its service life and improve operational efficiency.

During use, if encountering faults or questions that cannot be resolved, it is recommended to promptly contact the after-sales service team of SUNYE frequency converters for professional technical support and assistance. Through rational use and maintenance, the SUNYE CM530 series frequency converter will bring greater convenience and benefits to users’ industrial production.

Posted on Leave a comment

Operation Guide for Yuanshin Inverter YX300 Series User Manual

The Yuanshin Inverter YX300 series is a high-performance, low-noise inverter widely used in various industrial equipment. This document aims to provide users with an operation guide for this series of inverters, detailing how to control the inverter via its operation panel, how to set password and parameter access restrictions, how to initialize parameters, and how to achieve forward and reverse control via external terminals.

Actual operation picture of YX3000

1. Introduction to the Operation Panel and Basic Control

Operation Panel Function Introduction

The operation panel of the Yuanshin Inverter YX300 series features intuitive controls that allow users to easily monitor and manage the inverter’s operation. The following are the key functions and their corresponding operations:

  • Start/Stop the Inverter:
    • Start: Press the “RUN” button on the operation panel to start the inverter.
    • Stop: Press the “STOP/RESET” button to stop the inverter.
  • Set Frequency Using the Panel Potentiometer:
    • Rotate the potentiometer on the operation panel to adjust the output frequency of the inverter. This method is suitable for manual frequency adjustments during testing or initial setup.

Setting Password and Parameter Access Restrictions

  • Setting a Password:
    1. Press the “MENU” button to enter the parameter setting mode.
    2. Use the arrow keys to navigate to the password setting parameter (typically found in the PF group parameters).
    3. Enter the desired 4-digit password using the numeric keys.
    4. Press “ENTER” to confirm the password.
  • Accessing Restricted Parameters:
    • When attempting to access a restricted parameter, the inverter will prompt for the password. Enter the correct password to proceed.
  • Disabling the Password Function:
    • To disable the password function, simply set the password to “0000” and confirm.

Initializing Parameters

  • Parameter Initialization:
    1. Press the “MENU” button to enter the parameter setting mode.
    2. Navigate to the parameter initialization function (typically P3.01).
    3. Set the parameter to “1” to restore factory default settings.
    4. Press “ENTER” to confirm and initialize the parameters.
YX3000 standard wiring diagram for Yuanxin frequency converter

2. Forward and Reverse Control via External Terminals

Basic Wiring for External Control

To achieve forward and reverse control of the Yuanshin Inverter YX300 series via external terminals, you need to properly wire the control terminals. The following are the basic steps:

  1. Identify the Control Terminals:
    • FWD (Forward): Connect this terminal to a positive signal source to start the inverter in the forward direction.
    • REV (Reverse): Connect this terminal to a positive signal source to start the inverter in the reverse direction.
    • COM (Common): Common ground terminal for both FWD and REV.
  2. Wiring Configuration:
    • Connect the FWD terminal to a switch or relay contact that closes when you want the motor to run forward.
    • Connect the REV terminal to a switch or relay contact that closes when you want the motor to run reverse.
    • Ensure both FWD and REV terminals are connected to the COM terminal.
  3. Parameter Settings:
    • Set the operation command source to external terminals (P0.03 = 1).
    • Configure the frequency input method as desired (e.g., via potentiometer, analog signal, etc.).

Operation Example

  • Forward Operation:
    • Close the contact connected to the FWD terminal.
    • The inverter will start and run the motor in the forward direction.
  • Reverse Operation:
    • Close the contact connected to the REV terminal.
    • The inverter will start and run the motor in the reverse direction.
  • Stopping the Inverter:
    • Open both the FWD and REV contacts.
    • The inverter will stop the motor.

By following this operation guide, users can easily control the Yuanshin Inverter YX300 series via its operation panel and external terminals, setting passwords and parameter access restrictions as needed, and initializing parameters when required. This ensures efficient and secure operation of the inverter in various industrial applications.

Posted on Leave a comment

Siemens Inverter MM440 Series User Guide and Meaning of A503 Warning with Solutions

I. Introduction to MM440 Series Inverter Operating Panel Functions

1.1 Overview of Operating Panels

MM440 PICTURE

The Siemens MM440 series inverter is equipped with operating panels, including the Status Display Panel (SDP), Basic Operating Panel (BOP), and Advanced Operating Panel (AOP). These panels provide an intuitive interface for user interaction with the inverter, enabling monitoring, setting, and control of the inverter’s operation.

1.2 Setting Passwords and Parameter Levels

To prevent unauthorized changes, the MM440 inverter supports parameter locking and password protection. To set passwords and parameter levels, follow these steps:

  1. Enter Parameter Setting Mode: Use the BOP or AOP to press the “P” key to enter parameter setting mode.
  2. Select Password Parameter: Locate and set parameter P0012 (Unlocking of User-Defined Parameters) to your desired password.
  3. Lock Parameters: Set parameter P0011 (Locking of User-Defined Parameters) to 1 to enable password protection.

1.3 Restoring Factory Settings

To restore the inverter parameters to factory settings, follow these steps:

  1. Enter Parameter Setting Mode.
  2. Set P0010=30: Select the restore factory settings function.
  3. Set P0970=1: Confirm the execution of restoring factory settings.

1.4 Using BICO Functionality

The BICO (Binary Interconnect Connection) function allows users to program interconnections between internal signals and input/outputs of the inverter. To use the BICO function, follow these steps:

  1. Enter Parameter Setting Mode.
  2. Set Relevant BICO Parameters: For example, P0701 to P0708 are used to configure the functions of digital inputs, and P0731 to P0733 are used to configure the functions of digital outputs.
  3. Program Interconnection Logic: According to application requirements, use BICO control words and status words to program the desired interconnection logic.

II. Terminal Control and External Potentiometer Speed Regulation

2.1 Terminal Control

The MM440 inverter supports speed control via terminals. To achieve terminal control, follow these steps to set parameters and wiring:

  1. Set Command Source: Set parameter P0700 to 2 to select terminal control mode.
  2. Configure Digital Inputs: Configure parameters P0701 to P0708 as needed to specify the functions of each digital input (such as start, stop, direction control, etc.).
  3. Wiring: Connect external control signals (such as start and stop buttons) to the corresponding digital input terminals.

2.2 External Potentiometer Speed Regulation

An external potentiometer can be used to adjust the output frequency of the inverter, enabling speed regulation. The setup steps are as follows:

  1. Set Frequency Reference Source: Set parameter P1000 to 2 to select analog input as the frequency reference source.
  2. Configure Analog Input: Ensure that analog input AIN1 or AIN2 is correctly configured to receive a 0-10V or 0-20mA speed regulation signal.
  3. Wiring: Connect the output of the external potentiometer to the AIN1 or AIN2 terminal of the inverter, and ensure that the potentiometer is properly powered.
A503 WARNING CODE

III. Meaning of A503 Warning and Solutions

3.1 Meaning of A503 Warning

The A503 warning indicates that the inverter has detected undervoltage limitation, meaning that the DC link voltage is below the allowed minimum value. This can be caused by unstable supply voltage, input power failure, or internal inverter faults.

3.2 Solutions

  1. Check Supply Voltage: Ensure that the input supply voltage is within the allowed range and remains stable.
  2. Adjust Parameters:
    • Increase the ramp-down time (P1121) to reduce voltage drops during braking.
    • If the dynamic buffer function is enabled (P1240=2), adjust relevant parameters (such as P1243, P1245) to optimize performance.
  3. Check Inverter Internals: If the problem persists, it may be necessary to check the internal DC link and capacitors of the inverter for proper function.

3.3 Fault Codes and Meanings

The MM440 inverter has multiple fault codes that indicate different fault conditions. Here are some common fault codes and their meanings:

  • F0001: Overcurrent, usually caused by motor or cable short circuits, mismatched motor power, etc.
  • F0002: Overvoltage, possibly due to excessively high supply voltage or excessive regenerative energy generated during braking.
  • F0003: Undervoltage, indicating that the input supply voltage is below the allowed range.
  • F0004: Inverter overtemperature, usually caused by poor cooling or excessively high ambient temperature.
  • F0011: Motor overtemperature, possibly due to motor overload or poor cooling.

3.4 Fault Solutions

Methods for resolving inverter faults typically include checking the supply voltage, motor and cable connections, cooling system, and internal components of the inverter. Specific steps should be taken based on the indications of the fault code.

IV. Conclusion

This article provides a detailed introduction to the operating panel functions, terminal control and external potentiometer speed regulation setup methods, as well as the meaning and solutions of the A503 warning for the Siemens MM440 series inverter. Additionally, it outlines common fault codes, their meanings, and solutions. With the guidance of this article, users can better understand and utilize the MM440 series inverter to ensure stable equipment operation.

Posted on Leave a comment

Operation Guide for Senlan Inverter HOPE130 Series User Manual

I. Introduction to the Functions of the Inverter Operation Panel

The operation panel of the Senlan Inverter HOPE130 series offers a wide range of functions and an intuitive operating interface, making it convenient for users to set parameters, control operations, and monitor faults. Below are the primary functions of the operation panel:

Hope130 operation panel function diagram

1.1 Functions of the Operation Panel

  • Digital Display Area: Displays operational parameters such as frequency, current, and voltage.
  • Parameter Unit Display Area: Indicates the unit of the currently displayed parameter, such as Hz, A, V, etc.
  • Operational Status Indicator Area: Includes indicators like RUN (running) and FAULT (fault), used to show the current status of the inverter.
  • Keypad Area: Includes keys such as Menu/Exit, Program/Confirm, Increase, Decrease, Left Shift, Right Shift, Run, and Stop/Reset, used for parameter setting and operational control.

1.2 Restoring Factory Settings

To restore the factory settings of the inverter, follow these steps:

  1. Enter the parameter editing mode and press the Menu/Exit key to access the parameter group selection interface.
  2. Use the Increase or Decrease keys to select the F0 parameter group.
  3. Press the Program/Confirm key to enter the F0 parameter group editing interface.
  4. Use the Increase or Decrease keys to select the F0-11 parameter and set it to 11.
  5. Press the Program/Confirm key to save the setting, and the inverter will automatically restore to factory settings.

1.3 Setting and Removing Passwords

To set a password, follow these steps:

  1. Enter the parameter editing mode and select the F0 parameter group.
  2. Set the F0-13 parameter to the desired password value (0000~9999).
  3. Press the Program/Confirm key to save the setting.

To remove the password, simply reset the F0-13 parameter to 0000.

1.4 Parameter Locking

To prevent parameters from being accidentally modified, they can be locked. Follow these steps:

  1. Enter the parameter editing mode and select the F0 parameter group.
  2. Set the F0-12 parameter to 2 to enable full protection, locking all parameters.
Hope130 standard wiring diagram

II. Terminal Forward/Reverse Control and External Potentiometer Speed Regulation

2.1 Terminal Forward/Reverse Control

To achieve terminal forward/reverse control, the following parameters need to be set, and corresponding terminals need to be wired:

  • Parameter Settings:
    • F0-02: Operation Command Channel Selection, set to 2 (terminal control).
    • F4-06: FWD/REV Operation Mode, select the appropriate mode (e.g., Two-Wire Mode 1).
  • Wiring Terminals:
    • Connect the forward control signal to the X1 terminal and the reverse control signal to the X2 terminal.
    • Ensure the COM terminal is properly grounded.

2.2 External Potentiometer Speed Regulation

To achieve external potentiometer speed regulation, the following parameters need to be set, and corresponding terminals need to be wired:

  • Parameter Settings:
    • F0-01: Main Given Channel for Ordinary Operation, set to 4 (panel potentiometer).
    • If terminal control is desired, set to 5 (AI2) and connect the AI2 terminal to an external potentiometer.
  • Wiring Terminals:
    • If using the panel potentiometer, no additional wiring is required.
    • If using an external potentiometer, connect the two ends of the potentiometer to the AI2 and COM terminals.

III. Fault Code Analysis and Troubleshooting

The Senlan Inverter HOPE130 series provides a range of fault codes to help users quickly locate and resolve issues. Below are some common fault codes, their meanings, and solutions:

3.1 Er.ocb (Instantaneous Overcurrent at Startup)

  • Meaning: Inter-phase or ground short circuit within the motor or wiring, or damaged inverter module.
  • Solution: Check the motor and wiring, and seek professional service.

3.2 Er.ocA (Overcurrent During Acceleration)

  • Meaning: Too short acceleration time, inappropriate V/F curve, or restarting a rotating motor.
  • Solution: Extend the acceleration time, adjust the V/F curve, or set to speed tracking startup.

3.3 Er.ouA (Overvoltage During Acceleration)

  • Meaning: Abnormal input voltage or restarting a rotating motor.
  • Solution: Check the input power supply and set to speed tracking startup.

3.4 Er.dcL (Undervoltage During Operation)

  • Meaning: Abnormal input voltage or power loss during operation, heavy load impact, or damaged charging contactor.
  • Solution: Check the input power supply and wiring, inspect the load, and replace the charging contactor.

3.5 Er.oLL (Motor Overload)

  • Meaning: Inappropriate V/F curve, low input voltage, long-term low-speed heavy-load operation of a standard motor, or improper motor rating or overload protection settings.
  • Solution: Properly set the V/F curve and torque boost, check the input voltage, add an independent cooling fan or select an inverter-duty motor, and correctly set the motor parameters.

IV. Conclusion

The Senlan Inverter HOPE130 series user manual provides a detailed operation guide, covering the functions of the operation panel, restoring factory settings, setting and removing passwords, parameter locking, terminal forward/reverse control, external potentiometer speed regulation, and more. Additionally, the manual lists common fault codes, their meanings, and solutions to help users quickly locate and resolve issues. By carefully studying and mastering this operation guide, users can better utilize and maintain the Senlan Inverter HOPE130 series equipment.

Posted on Leave a comment

Operation Guide for Yaskawa V1000 Series Inverter User Manual

The Yaskawa V1000 series inverter, as a high-performance vector control inverter, is widely used in various industrial drive systems. This article will provide a detailed introduction to the operation panel functions, basic setting methods, common function applications, and fault code analysis of this inverter, helping users better understand and utilize this equipment.

Function diagram of V1000 operation panel

I. Introduction to Operation Panel Functions and Basic Settings

1. Introduction to Operation Panel Functions

The operation panel of the Yaskawa V1000 series inverter integrates rich display and control functions, mainly including the LED operator, LO/RE indicator light, RUN indicator light, etc. Users can perform parameter settings, mode switching, operation monitoring, and other operations through the operation panel.

2. How to Set and Clear Passwords

To protect the inverter parameters from being modified arbitrarily, users can set a password. The specific steps are as follows:

  • Setting a Password: In the parameter setting mode, find A1-04 (password setting), enter the desired password value, and then press the ENTER button to confirm. Next, enter the same password value in A1-05 (password) for confirmation.
  • Clearing a Password: To clear the set password, simply set the password values in both A1-04 and A1-05 to 0.

3. Parameter Initialization

When it is necessary to restore the inverter to its factory default settings, parameter initialization can be performed. The specific steps are as follows:

  • In the parameter setting mode, set A1-03 to 2220 (2-wire sequence control initialization) or 3330 (3-wire sequence control initialization), and then press the ENTER button to confirm. At this point, the inverter will be restored to its factory default settings.

4. Using the DWELL Function

The DWELL function can temporarily maintain the output frequency during motor startup or stoppage to prevent motor stall. The specific setting steps are as follows:

  • In the parameter setting mode, find b6-01 and b6-02, and set the DWELL frequency and time during startup respectively. For example, set b6-01 to 5Hz and b6-02 to 2s, so that the motor will maintain a 5Hz output for 2 seconds during startup.

5. Using the Speed Search Function

The speed search function can automatically search and set the appropriate output frequency when the motor stalls or restarts. The specific usage method is as follows:

  • In the parameter setting mode, set b3-05 to the speed search wait time (e.g., 1s). Then, trigger the speed search function through an external signal when needed, and the inverter will automatically search and set the appropriate output frequency.
V1000 labeled wiring diagram

II. Terminal Functions and Wiring Settings

1. Realizing Forward and Reverse Start/Stop Functions

To realize the forward and reverse start/stop functions of the motor, it is necessary to correctly wire and set relevant parameters. The specific steps are as follows:

  • Wiring: Connect the forward start signal to terminal S1, the reverse start signal to terminal S2, and the stop signal to terminal S3.
  • Parameter Settings: In the parameter setting mode, set b1-02 to 1 (LOCAL/REMOTE selection), and set H1-01 and H1-02 to the input terminals for forward and reverse commands (e.g., S1 and S2) respectively. At the same time, set H1-03 to the input terminal for the stop command (e.g., S3).

2. Realizing External Potentiometer Speed Regulation

The external potentiometer speed regulation function allows users to change the output frequency of the inverter by adjusting the resistance value of an external potentiometer. The specific implementation method is as follows:

  • Wiring: Connect the output signal of the external potentiometer to terminal A1 of the inverter (multi-function analog input terminal).
  • Parameter Settings: In the parameter setting mode, set b1-01 to 1 (control circuit terminal frequency command), and set H3-01 to 0 (0~10V input). At the same time, adjust the values of H3-04 (input gain) and H3-05 (input offset) according to actual needs.

III. Fault Code Analysis

The Yaskawa V1000 series inverter has a comprehensive fault diagnosis function. When a fault occurs in the inverter, the corresponding fault code will be displayed on the operation panel. The following are some common fault codes, their meanings, and solutions:

  • CPF02: A/D converter fault. Possible causes include control circuit damage, control circuit terminal short circuit, etc. Solutions include checking the control circuit connection and replacing the inverter.
  • CPF06: EEPROM data anomaly. Possible causes include control circuit damage, power being cut off during the initialization process, etc. Solutions include re-executing the initialization operation and replacing the inverter.
  • Uv1: Main circuit undervoltage. Possible causes include too low power supply voltage, power supply phase loss, etc. Solutions include checking the power supply voltage and power supply wiring.
  • oH1: Heatsink overheat. Possible causes include too high ambient temperature, excessive load, etc. Solutions include improving heat dissipation conditions and reducing the load.

When a fault occurs in the inverter, users should refer to the fault code displayed on the operation panel, combine the above analysis methods and solutions for troubleshooting and handling. If the problem cannot be solved, users should promptly contact professional technicians for repair.

IV. Conclusion

The Yaskawa V1000 series inverter, as a high-performance vector control inverter, boasts rich functions and flexible setting options. Through the introduction in this article, users can better understand and utilize this equipment to achieve precise motor control and efficient operation. At the same time, users should also regularly check and maintain the inverter to ensure its long-term stable operation.

Posted on Leave a comment

Operation Guide for Goodbell G500/G600 Series Frequency Converter User Manual

I. Introduction to the Operation Panel Functions and Parameter Settings

The operation panel of the Goodbell G500/G600 series frequency converter serves as the primary interface for users to control and monitor the converter. The operation panel features multiple functional buttons and a digital display, enabling users to easily perform various operations such as setting parameters, monitoring the operating status, and controlling the start and stop of the converter.

1. Introduction to Operation Panel Functions
  • RUN Indicator: When the light is off, the converter is stopped. When the light is on, the converter is running.
  • LOCAL/REMOT Indicator: Indicates the operation mode of the converter. Off indicates keyboard operation, on indicates terminal operation, and flashing indicates remote operation (via communication control).
  • FWD/REV Indicator: Indicates the rotation direction of the motor. The light is on when rotating forwards.
  • TUNE/TC Indicator: Indicates torque control mode when lit, tuning mode when flashing slowly, and fault status when flashing quickly.
  • Digital Display: A 5-digit LED display that shows set frequency, output frequency, various monitoring data, and alarm codes.
  • Keyboard Buttons: Include buttons for programming, entering, increasing/decreasing values, shifting, running, stopping/resetting, and multi-function selection.
2. Setting and Removing Passwords
  • Setting Password: To set a password, modify parameter PP-00 to a non-zero value. Once set, users must enter the correct password to access the parameter menu.
  • Removing Password: To remove the password protection, enter the password, then set PP-00 to 0.
3. Setting Parameter Lock
  • Parameter Lock: To lock parameters, modify parameter PP-04 to “1” for the parameters you wish to lock. This prevents unauthorized modification of critical settings.
4. Restoring Parameter Initialization Settings
  • Restoring Defaults: To restore the factory default settings (excluding motor parameters), set parameter PP-01 to “01”. To restore user-backed up parameters, set PP-01 to “501”.

II. Terminal Connections for Forward/Reverse Start and External Potentiometer Speed Adjustment

1. Forward/Reverse Start

To achieve forward/reverse start control of the motor using the converter, you need to connect the appropriate terminals on the converter. Specifically:

  • Forward Start: Connect the control signal to the DI1 terminal (set P4-00 to “1” for forward run).
  • Reverse Start: Connect the control signal to the DI2 terminal (set P4-01 to “2” for reverse run).
2. External Potentiometer Speed Adjustment

To adjust the motor speed using an external potentiometer, connect the potentiometer’s output to the AI1, AI2, or AI3 terminal (depending on the setting of the frequency source in parameter P0-03). Ensure that the potentiometer’s output range matches the input range configured in the converter.

Wiring Instructions

  1. Power Supply Connections: Ensure proper connection to the R, S, T terminals for three-phase power supply, or L1, L2 for single-phase supply.
  2. Motor Connections: Connect the motor’s U, V, W terminals to the corresponding terminals on the converter.
  3. Control Signal Connections:
    • For forward/reverse control, connect the control signals to DI1 and DI2 terminals as described above.
    • For speed adjustment using an external potentiometer, connect the potentiometer’s output to AI1, AI2, or AI3, and configure the relevant parameters accordingly.
  4. Grounding: Ensure reliable grounding of the PE terminal to prevent electrical hazards.

By following these guidelines and the detailed instructions in the user manual, users can effectively operate and configure the Goodbell G500/G600 series frequency converter to meet their specific application requirements.

Posted on Leave a comment

Operation Guide for MICFIND Frequency Inverter MT500 Series User Manual

I. Introduction to Operation Panel Functions and Parameter Settings

1.1 Introduction to Operation Panel Functions

The MICFIND Frequency Inverter MT500 Series is equipped with a powerful operation panel that allows users to conveniently set parameters, monitor the inverter’s status, and troubleshoot through the keypad and display. The main function keys on the operation panel include:

  • ESC: Returns to the previous menu.
  • ENTER: Confirms selections, enters the next menu level, or applies parameter changes.
  • UP/DOWN: Moves the cursor up or down to select function codes or change parameter values.
  • M.K: Multifunction key, defaulted to “Jog Forward” function, customizable.
  • SHIFT: Moves the cursor to the right, switches monitored values.
  • RUN: Starts the inverter.
  • STOP: Stops the inverter or resets it in case of a fault.
ER.OLP fault

1.2 Setting and Removing Passwords

To prevent unauthorized personnel from changing inverter parameters, the MT500 Series supports user password settings. The specific operations are as follows:

  • Setting a Password: In the stopped state, enter the same non-zero value twice to set the user password.
  • Unlocking and Changing the Password: After entering the password, press ENTER twice to unlock. Enter the new password twice to change it.
  • Removing the Password: After unlocking, enter “0” twice to clear the password.

1.3 Parameter Locking and Initialization

  • Parameter Locking: After setting a user password, the parameters are automatically locked. Only partial parameters are accessible without unlocking. Users need to enter the password to unlock and access all parameters.
  • Parameter Initialization: In the stopped state, set parameter P00.03 to “11” to restore factory settings (excluding motor parameters), “12” to restore all factory settings (including all non-factory parameters), or “13” to clear fault records. After setting the parameter, re-power the inverter.

II. Terminal Control and External Speed Regulation

2.1 Terminal Forward/Reverse Control

To achieve forward/reverse control through terminals, external control signals need to be connected to the inverter’s DI terminals. The specific wiring and parameter settings are as follows:

  • Wiring: Connect the forward control signal to the DI1 terminal and the reverse control signal to the DI2 terminal.
  • Parameter Settings: Set P06.01 (DI1 Function Selection) to “2” (Reverse Run/Forward-Reverse Switch) and P06.02 (DI2 Function Selection) to “1” (Forward Run).

2.2 External Potentiometer Speed Regulation

External potentiometer speed regulation is achieved through analog input. The specific wiring and parameter settings are as follows:

  • Wiring: Connect the output end of the external potentiometer to the AI1 terminal and the other end to the AI1 COM terminal.
  • Parameter Settings: Set P01.00 (Main Frequency Source Selection) to “1” (AI1). Ensure that parameters such as P04.01 (HDI Maximum Input Frequency) and P04.02 (HDI Minimum Frequency Corresponding Conversion Value) are set according to actual needs.
MT500 standard wiring diagram

III. Fault Codes and Troubleshooting

The MT500 Series inverter has comprehensive protection functions. When a fault occurs, a corresponding fault code is displayed. Below are some common fault codes, their meanings, and troubleshooting methods:

  • Er.GF: Ground short circuit. Possible causes include poor motor insulation or damaged cables. Troubleshooting methods include checking motor insulation resistance and cable connections.
  • Er.tCK: Module temperature detection abnormality. Possible causes include low ambient temperature or hardware faults. Troubleshooting methods include increasing the ambient temperature or seeking technical support.
  • Er.Cur: Current detection fault. Possible causes include abnormal current detection components or drive boards. Technical support is required.
  • Er.PGL: Encoder disconnection. Possible causes include motor stall or incorrect encoder line number settings. Troubleshooting methods include checking the motor and mechanical conditions and correctly setting encoder parameters.
  • Er.oS: Motor overspeed fault. Possible causes include incorrect encoder parameter settings or lack of parameter identification. Encoder parameters need to be correctly set, and motor parameter identification needs to be performed.

IV. Conclusion

The MICFIND Frequency Inverter MT500 Series User Manual provides a detailed operation guide, including introductions to operation panel functions, parameter settings, terminal control, external speed regulation, and fault troubleshooting. Through this guide, users can quickly master the basic operation methods and fault troubleshooting methods of the inverter, ensuring its normal operation and efficient use. In practical applications, users should set parameters reasonably according to specific needs and regularly maintain the inverter to extend its service life and improve operational efficiency.

Posted on Leave a comment

Operation Guide for CHINSC S350N Series Inverter User Manual

I. Introduction to the Operating Panel Functions and Basic Settings

The CHINSC S350N series of inverters feature a comprehensive operating panel that provides functions such as operation monitoring, parameter modification, and fault alarm. Here are some basic functions and setting methods of the operating panel:

  1. Operating Panel Function Introduction
    • RUN Indicator Light: Off indicates that the inverter is stopped, and on indicates that the inverter is running.
    • REMOT Indicator Light: Off represents keyboard operation control, on represents terminal operation control, and flashing indicates remote communication operation control.
    • REV Indicator Light: On indicates that the inverter is in reverse operation.
    • FAULT Indicator Light: Slow flashing indicates the tuning state, and fast flashing indicates a fault state.
  2. Setting and Eliminating Passwords
    • Setting Password: Modify the function code H7-03 to set a password. Setting H7-03 to a non-zero value will establish a user password. After setting, pressing the ENTER key in the normal interface will prompt for the correct password to proceed with parameter settings.
    • Eliminating Password: After correctly entering the password, set H7-03 to 0 to eliminate the password.
  3. Parameter Initialization
    • Use function code HP-01 for parameter initialization. Selecting HP-01 as 01 will restore factory parameters (excluding motor parameters); selecting 02 will clear recorded information; selecting 03 will restore all factory parameters.
  4. Locking Keyboard Parameters
    • Use function code HP-04 to lock parameters. Setting HP-04 to 1 will make all parameters except this one readable but not writable, enabling parameter locking.

II. Terminal Forward/Reverse Control and External Potentiometer Speed Regulation

The CHINSC S350N series of inverters supports multiple control methods, including terminal forward/reverse control and external potentiometer speed regulation. Here are the specific wiring and parameter setting methods:

  1. Terminal Forward/Reverse Control
    • Terminals to Wire: Connect the forward control to terminal S1, reverse control to terminal S2, and the common terminal to COM.
    • Parameter Settings:
      • Set H0-13 to 0 (two-wire mode 1), H4-00 to 1 (S1 for forward operation), and H4-01 to 2 (S2 for reverse operation).
      • Or set H0-13 to 1 (two-wire mode 2), H4-00 to 1 (S1 for operation enable), and H4-01 to 2 (S2 for operation direction).
  2. External Potentiometer Speed Regulation
    • Terminals to Wire: Connect the external potentiometer to terminals V1 and GND.
    • Parameter Settings:
      • Set H0-00 to 2 (V1), indicating that the main frequency source A is the external potentiometer input.
      • Adjust H0-08 (digital frequency setting) and other related parameters as needed.

III. Fault Codes and Solutions

The CHINSC S350N series of inverters comes with comprehensive fault diagnosis capabilities. Here are some common fault codes, their possible causes, and solutions:

  1. E001 – Inverter Unit Protection
    • Possible Causes: Short circuit in the inverter output circuit, excessive wiring length between the motor and inverter, loose internal wiring of the inverter, or abnormal main control board.
    • Solution: Eliminate external faults, install reactors or output filters, securely connect all wires, or replace the circuit board.
  2. E002 – Acceleration Overcurrent
    • Possible Causes: Too short acceleration time, vector control mode without parameter identification, inappropriate manual torque boost or V/F curve.
    • Solution: Increase the acceleration time, perform motor parameter identification, or adjust the manual torque boost or V/F curve.
  3. E003 – Deceleration Overcurrent
    • Possible Causes: Too short deceleration time, vector control mode without parameter identification, sudden load increase during deceleration.
    • Solution: Increase the deceleration time, perform motor parameter identification, or eliminate sudden load increases.
  4. E004 – Constant Speed Overcurrent
    • Possible Causes: Vector control mode without parameter identification, sudden load increase during operation, or undersized inverter selection.
    • Solution: Perform motor parameter identification, eliminate sudden load increases, or select an inverter with a higher power rating.
  5. E010 – Inverter Overload
    • Possible Causes: Excessive load or motor stall, or undersized inverter selection.
    • Solution: Reduce the load and check the motor and mechanical conditions, or select an inverter with a higher power rating.
  6. E015 – External Device Fault
    • Possible Cause: External fault signal input through multifunction terminal S.
    • Solution: Reset the operation.

IV. Conclusion

The CHINSC S350N series inverter user manual provides detailed operation guidance and fault troubleshooting methods. By understanding the functions of the operating panel, mastering parameter setting methods, familiarizing oneself with terminal wiring, and fault codes, users can better use and maintain the inverter, ensuring its stable operation. In practical applications, users should flexibly adjust parameter settings according to specific situations, promptly troubleshoot and resolve faults, thereby improving production efficiency and equipment reliability.
